Server Technology C2S36TE-2CAF2M99 Smart Master Pro2 Hdot Outlets

Server Technology C2S36TE-2CAF2M99 Smart Master Pro2 36-Configurable Alt-Branch Hdot Outlets - 208V - 3BR - 30A - L6-30P The Server Technology PRO2 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Smart Master PDU can be connected to as many as three (with optional module) PRO2 Smart Link PDU to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration. Model number C2S36TE-2CAF2M99 Product Name Server Technology C2S36TE-2CAF2M99 Smart Master Pro2 Hdot Outlets Product Type Hdot Outlets Input Voltage 208 V Input Plug Type NEMA L6-30P Input Current 30 A Input Current Rated 24 A Input Power Capacity 5 KW Connector (18) x IEC 60320/C13: North American Rating: ? 12A @208V L-L (15A Peak); (18) x Cx: North American Rating: ? 16A @208V L-L (20A Peak) Operating Environment 32degF to 140degF / 0degC to 60degC | 8%RH to 90%RH non-condensing | 6,500ft/2km elevation Storage Environment -40degF to 185degF / -40degC to 85degC | 8%RH to 90%RH non-condensing | 50,000ft/15km elevation Communications & Security 10/100/1000 Mbps Ethernet (RJ-45 connector), RS-232 serial (RJ-45 connector); Two (2) temperature/humidity sensor inputs (4P4C), Link port (RJ-12) - {also on Link PDU}; Web-browser GUI and command-line interface (CLI): HTTP/HTTPS, TLSv1.2, SSHv2, Telnet, SNMPv2c and v3 (GET, SET, Traps), IPv4 and IPv6, LDAPv3/LDAPS, TACACS+, RADIUS, FTP/SFTP LED Current +- 10% at 0.1 amp (0.3 - 9.9 amps) and 1 amp (> 9.9 amps) resolution GUI Current +- 1% at 0.01 amp resolution (above 0.25 amp) Voltage 1% at 0.1 volt resolution (nominal +- 10%) Active Power +- 1% at 1 watt resolution Apparent Power +- 1% at 1 volt-amp resolution Power Factor +- 3% at 0.01 resolution Crest Factor +- 10% at 0.1 resolution Energy +- 1% at 0.1 kilowatt-hour resolution Branch Measurement Accuracy Current = +- 3% at 0.01 amp resolution (above 0.5 amp) Branch Circuit Protection UL489 Compliant 2-pole, 20A trip circuit breakers, three (3) branch, rating: ? 16A, 10 kAIC Interrupt Rating Dimensions 70 tall x 2.2 wide x 2.5 deep inches / [1778mm x 56mm x 64mm]
