Server Technology PRO1 Primary PDU

Server Technology C1W24VT-5PPA17AC/C Switched PRO1 PIPS PDU - 24x IEC C13 Outlets - 415v - 3-phase - 30a The Server Technology PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched Primary PDU can be connected to as many as three (with optional module) PRO1 Switched Link PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration. Model Number PRO1 Product Name Server Technology PRO1 Primary PDU Product Type PDU Network Monitoring Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more. Star Multi-Linking PRO1 provides the ability to link up to four power circuits using one IP address. Primary Expansion PDU provides backup power to network card. IP Access, Security & Communications Web, SSH, Telnet, SNMPv2c & v3, RS-232 serial, 10/100 Base T-Ethernet, LDAP(S), TACACS+, RADIUS, DHCP, & SMTP/email. Per-Inlet Power Sensing PIPS (Per Inlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor, Power Factor, & Energy per inlet. Outlet Control On Switched PDUs, cycle power to individual outlets or groups of outlets to reboot servers, or power off unused receptacles. High Temperature Rating This product has been tested and approved for safe and reliable operation in 60 C data center environments. Color-Coded Options Select from six colors to designate PDU circuits in the data center black, white, red, green, blue, and yellow. Hot-Swap Network Card Network access is ensured when power is lost to the Primary unit with backup power provided by the Linked unit. Temperature/Humidity Monitoring Supports two external 10'' (3m) T/H probes. Receive SNMP-based alerts and email notifications. Auto-Flip Current Display Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high density cabinets. Branch Circuit Protection UL 489, CSA C22.2 No. 5 & IEC/EN60947-2 Compliant 1-pole, 20A trip circuit breakers, six (6) branch, rating: 16A, 5 kAIC Interrupt Rating High Retention Locking Outlets PRO1 receptacles have high retention and are compatible with P-Lock type power cords. Flexible Mounting Includes standard button mounts along with provisions for custom mounting brackets. Input Voltage (V) 415 Frequency 50/60 Hz Input Plug 240/415V Wye 30A IEC 60309 3P+N+G 6Hr Input Current (A) 30 Input Current Rated (A) 24 Input Power Capacity (kW) 17.3 Input Phase 3-Phase Wye (L-N) Input Cord Location Bottom/End Outlet Form Factor Conventional Connector Rating (24) x IEC 60320/C13 North American Rating: 12A @240V L-N(15A Peak) Branch Monitoring Sense Branch Overcurrent Protection 5 kAIC Branch Overcurrent Protection Type Circuit Breaker: 1-pole Dual Input No High Retention Outlets Yes Input Current Display Auto-Orient Locking Outlets Yes Fast Movers No Mounting 0U Vertical Outlet Monitoring None Physical Dimensions: 69.0in tall x 1.75in wide x 3.5in deep [1753mm x 45mm x 89mm] Environmental Operating Environment: 32F to 140F / 0C to 60C Communications & Security 10/100 Mbps Ethernet (RJ-45 connector), RS-232 serial (RJ-45 connector) Certifications North American: Measurement Accuracy Input Measurement Accuracy:
